Kulzer cara Print LEDcure Light Curing Unit (LED Style) For 3D Print Resins - 66078521 - 1 Unit
- Brand: Kulzer
- Product Code: K-CPLED
SPECIAL ORDER ITEM - 1 WEEK LEADTIME
Kulzer cara Print LEDcure Light Curing Unit (LED Style) For 3D Print Resins - 66078521 - 1 Unit
cara Print LEDcure offers the flexibility to set the time, temperature and LED intensity to ensure optimal illumination conditions for all opaque & transparent 3D print materials.
cara Print LEDcure features long-life LEDs for both 385 and 405nm resins, a transparent turntable so there’s no need to flip objects, and a fan-assisted heater. All this creates a stable thermal environment for more complete bond formation and excellent mechanical properties in terms of flexural strength, elongation at break, edge strength and colour stability – and restorations won’t come out sticky.
Laboratories using our dima Print materials will find preset illumination programs for quick, yet dependable results. The device also allows for more than 100 additional customizable programs for post-curing other 3D resins.
Cover all your post-curing needs in a reliable, yet simple process.
Flexible: individually set time, temperature & intensity for all 3D resins.
Large chamber (fits 4-5 models) with long-life LEDs.
Optimal illumination conditions for all opaque & transparent 3D print materials (385 and 405 nm resins).
Ideal, homogeneous curing, no flipping, objects not “sticky” after curing.
Factory-set programs (time, intensity, temp.) for dima Print materials & storage for 100+ programs for other materials.
Fan-assisted heater for more complete bond formation & optimal mechanical properties.
Made in Germany incl. CE and cUL.
Technical details | |
---|---|
Unit size (W x D x H) | 250 x 350 x 380 mm (550 mm high with open door) |
Unit weight | 12.8 kg |
Illumination chamber dimensions (W x D x H) | 170 x 200 (at base) x 170 mm |
Transparent rotating plate diameter | 150 mm ∅ (= usable space) |
Light source | IEC Class I |
Illumination source | 10 LED modules w/ 5 LEDs with 3 watt each (= 150 Watt LED power) |
Program settings | |
---|---|
Temperature range | 30 – 80°C Note: can be operated with no heating |
Time range | 1 – 30 minutes |
Intensity | 10 – 100 % (i.e. 15 – 150 LED illumination intensity) |
